Duplication

Previous pageReturn to chapter overviewNext page

All objects in a 20-sim Animation can be duplicated. This property is useful when drawing a lot of the same objects.

3DAnimationDuplication

You can choose several options:

Number of Duplicates: Select the number of duplicates of the object.
Position Offsets: Select the position offset of the first duplicate from the original object. This offset is repeated for every next duplicate.
Orientation Offset: Select the orientation offset of the first duplicate from the original object. This offset is repeated for every next duplicate.
Scaling Offset: Select the scaling of the first duplicate compared to the original object. This scaling is repeated for every next duplicate.



The example below shows a cube that is duplicated according to the specifications given in the figure above. As shown, the first duplicate is a little larger than the original object. The second duplicate is a little larger than the first duplicate etc.

3DAnimationDuplicationResult
